Signal Lamps

SIGNAL LAMPS FOR CHECKOUT COUNTER

lampionciniSignalling the counter status and its number is information that needs to be communicated to the customers.

All of our solutions use LED lighting, so as to be able to exploit the flexibility and low power consumption that together with polymethylmethacrylate allow us to carry out projects that combine an appealing aesthetic look with a functional one.

MIRK model

Led Mod MIRK		 Lamp in transparent PMMA with central area that turns green or red according to the counter status.
Counter number to apply, with front/rear view

There are two models: Quadro (Square) and Goccia (Drop),
with two lightning finishings: Retinato (Screened) and Diffuso (Diffused),
with two types of fixing: cantilevered for vertical (pole) and horizontal (hanging) assembly
Power supply 12V 350mA

MIY model
Led Mod MIY		 Lamp in painted sheet with lateral tube that turns green or red according to the counter status.
Counter number to apply, with front/rear view

The Tube model is available and the models OpenClose and Message are foreseen.
For Tube model, the assembly is cantilevered for vertical (pole) and horizontal (hanging) fixing, so 4 tube positions are possible: high, low, right and left.
Power supply 12V 350mA




DIGI model


Lamp in transparent PMMA with central area indicating the number of counter that turns green or red according to the counter status.
Press the hidden button in the left upper part of the 1st figure, which is accessible by a small hole, to move forward the current number.

There are two models:
Front or Front and Rear counter number,
with number: of one figure or two figures
with two LED screen: Opal white and Smoked,
Assembly is cantilevered vertical (pole).
Power supply 12V 350mA
Power Supply



Universal power supply for all the lamps of 12V 350mA
it is present in two models:

  •     Independent:

    With a 2m cable and Schuko plug to connect to the mains supply (230Vac). It contains: a power switch and one for the selection of green and red colour. A 5m cable with connector allows connecting to the lamp

  •     To Checkout counter:

    To be connected to the Electrical board of the checkout counter to the output to control the mains voltage lamps, by a 3m cable. The Electrical board controls allow selecting the desired colour. A 5m cable with connector allows connecting to the lamp.


    Adhesive numbers

         		       For lamps in which it is necessary to apply the number there is a Kit of black adhesive numbers (or different colours upon request)

        • Kit numbers 1-10
        • Kit numbers 1-20
        • Kit numbers 1-30
        • Kit numbers 1-40
        • Kit numbers 1-50

    numbers size: 100x60mm
